RFI CSM500 3.5dBi Ultra Compact Antenna with 1.5m Cable and SMA Connector
In stock
Only 6 left
MPN
CSM500-1.5M-SMA
SKU
RFI-CSM500-1.5M
$82.50
Quick Overview
RFI CSM500 3.5dBi Ultra Compact Antenna with 1.5m Cable and SMA Connector
FAST DELIVERY
On all in-stock items
Related Products
Check items to add to the cart or
The CSM500 is an ultra-compact omnidirectional 4G LTE antenna that provides excellent coverage for mobile and fixed data applications from 698 MHz to 2.7 GHz. The antenna features an attractive, compact housing which can be used in both indoor and outdoor applications. The CSM500 is fitted with a 11.9mm stud mount incorporating an integrated double-sided foam seal and is IP69 rated.
Features:
- Covers all 4G LTE & 3G cellular bands
- Screw mount with anti-rotation mechanism
- Ground plane independent
- Ultra-compact design: Ø 50 x 50.8 mm
- Weatherproof: IP69
Other standard version available:
- CSM500 with 5M cable terminated with SMA male connector
| Manufacturer | RF Industries |
|---|---|
| Colour | Black |
| Antenna Frequency | 698 - 960 / 1710 - 2170 / 2300 - 2700 MHz |
| Antenna Gain | 3.6 / 4.1 / 1.9 dBi |
| Antenna Length | 50.8mm |
| Removable Whip | N/A |
| Diameter | 50mm |
| Strength | Standard Duty |
| Mounting | 13mm Stud |
| Cable Length | 1.5m |
| Cable Type | LL100 |
| Connector | SMA (Male) |
| Antenna Material / Construction | UV Stable Black Polycarbonate Radome |
| Antenna Power | 25W |
| VSWR | <2.5:1 |
