RFI CSM500 3.5dBi Ultra Compact Antenna with 5m Cable and SMA Connector
Overview:
- We use Australia Post for most of our deliveries.
- Orders are typically processed and shipped with tracking details within 1-3 business days. You can expect your parcel within 2-8 business days from when it leaves our warehouse.
- For more info, visit our Delivery or Refunds & Returns pages.
SKU | RFI-CSM500-5M-SMA |
---|---|
Manufacturer | RF Industries |
Colour | Black |
Antenna Frequency | 698 - 960 / 1710 - 2170 / 2300 - 2700 MHz |
Antenna Gain | 3.6 / 4.1 / 1.9 dBi |
Antenna Length | 50.8mm |
Removable Whip | N/A |
Diameter | 50mm |
Strength | Standard Duty |
Mounting | 13mm Stud |
Cable Length | 5m |
Cable Type | LL100 |
Connector | SMA (Male) |
Antenna Material / Construction | UV Stable Black Polycarbonate Radome |
Antenna Power | 25W |
VSWR | <2.5:1 |
The CSM500 is an ultra-compact omnidirectional 4G LTE antenna that provides excellent coverage for mobile and fixed data applications from 698 MHz to 2.7 GHz. The antenna features an attractive, compact housing which can be used in both indoor and outdoor applications. The CSM500 is fitted with a 11.9mm stud mount incorporating an integrated double-sided foam seal and is IP69 rated.
Features:
- Covers all 4G LTE & 3G cellular bands
- Screw mount with anti-rotation mechanism
- Ground plane independent
- Ultra-compact design: Ø 50 x 50.8 mm
- Weatherproof: IP69
Other standard version available:
- CSM500 with 1.5M cable terminated with SMA male connector

RFI CSM500 3.5dBi Ultra Compact Antenna with 5m Cable and SMA Connector
